Product Description
DB-AIRE II AIR-COOLED DX & CHILLED WATER SYSTEMS
Today's technology rooms require precise, stable environments and design in order for sensitive electronics to
operate optimally. Precision air conditioning is designed for close temperature and humidity control. It provides high
reliability operation with the ease of service, system flexibility and redundancy necessary to keep the electronic
equipments up and running 24 hours a day, 365 days a year.
DB-AIRE II another milestone series offers a wide range of capacities in superior compact, stylish black themed
attractive furniture grade cabinets in Upflow/ Downflow configuration to provide room-based cooling, control of
perfect humidification and air filtration.

DB-AIRE II DESIGN FEATURES

PHYSICAL DATA |
MODEL |
DBAD/U 02 DBRD/U 02 |
DBAD/U 03 DBRD/U 03 |
DBAD/U 04 DBRD/U 04 |
DBAD/U 05 DBRD/U 05 |
DBAD/U 07 DBRD/U 07 |
DBAD/U 09 DBRD/U 09 |
Height |
H |
mm (inch) |
1944 (76.5) |
1944 (76.5) |
1944 (76.5) |
1944(76.5) |
1944 (76.5) |
1944 (76.5) |
Width |
W |
mm (inch) |
749 (29.5) |
749 (29.5) |
749 (29.5) |
749 (29.5) |
1464 (57.6) |
1464 (57.6) |
Depth |
D |
mm (inch) |
874 (34.4) |
874 (34.4) |
874 (34.4) |
874 (34.4) |
874 (34.4) |
874 (34.4) |
Weight |
DBAD/U |
kg (lbs) |
251 (552) |
259 (570) |
260 (572) |
272 (598) |
420 (924) |
450 (990) |
DBRD/U |
kg (lbs) |
265 (583) |
273 (601) |
274 (603) |
286 (629) |
442 (972) |
472 (1038) |
472 (1038) |
